Vault Series 230V Tower UPS

$0.00

Topology: True on-line, double conversion with integral automatic bypass
Power Rating: 700VA - 3kVA
Input Connection: Fixed AC Power Cord (see model specifications for connector type)

Product Overview & Certifications

Ideal for mission-critical and sensitive applications, this UPS ensures your connected equipment remains fully shielded from power fluctuations, including spikes, surges, electrical noise, voltage irregularities, harmonics, and frequency variations. When ultimate reliability matters, the Vault Series is your frontline defense.

CE conformity mark — Various (based on model)

UL certification mark — UL Certified #E316102

ETL Listed #4008408

    Key Features
    True sine-wave output with less than 3% THD
Output voltage regulation to within +/- 2%
High Efficiency (HE) & Free-run mode
EPO (Emergency Power Off) port
Power monitoring & UPS control software
RS-232 & USB communication interface
Multi-function, interactive control panel & LCD display



    Applications
    Medical & Imaging*
Industrial Automation
Process & Motion Control
Laboratory, Test & Measurement
OEM Equipment
Communications & Guidance
Security & Safety



VTWE 230V Model Specifications

Model	Capacity	Input Plug	Input Current	Output Connection	Dimensions W x D x H (in/mm)	Weight (lbs/kgs)
VTWE-0700-02	700VA • 490W	IEC C14 (10A)	2.49A	6 x NEMA 5-15R	6 x 16.5 x 9.4 / 152 x 420 x 238	29.7 / 13.5
VTWE-1000-02	1000VA • 700W	IEC C14 (10A)	3.56A	6 x NEMA 5-15R	6 x 16.5 x 9.4 / 152 x 420 x 238	35.7 / 16.2
VTWE-1500-02	1500VA • 1050W	IEC C14 (10A)	5.34A	6 x NEMA 5-15R	6 x 16.5 x 9.4 / 152 x 420 x 238	37.4 / 17
VTWE-2000-02	2000VA • 1400W	IEC C14 (10A)	7.13A	12 x NEMA 5-15R	8.9 x 16.7 x 14.2 / 225 x 425 x 360	69.5 / 31.6
VTWE-3000-02	3000VA • 2100W	IEC C14 (16A)	10.69A	12 x NEMA 5-15R	8.9 x 16.7 x 14.2 / 225 x 425 x 360	72.6 / 33

Battery Specifications

Model	Battery Type & Rating	Battery Quantity	Internal Battery Cartridge
VTWE-0700-02	Sealed, lead acid 7.2Ah/12V (36W)	2	VTBC-0700-24
VTWE-1000-02	Sealed, lead acid 7.2Ah/12V (36W)	3	VTBC‐1000‐36
VTWE-1500-02	Sealed, lead acid 9Ah/12V (45W)	3	VTBC‐1500‐36
VTWE-2000-02	Sealed, lead acid 7.2Ah/12V (36W)	5	VTBC‐1000‐36
VTWE-3000-02	Sealed, lead acid 9Ah/12V (45W)	6	VTBC‐1500‐36
